Yokogawa 2051 03 直流毫安电流表

Max. Scale Value: 10/30/100/300/1000 mA DC

Approximate Internal Resistance and Consumed Power: 4/1.4/0.4/0.14/0.04 Ω

Operating Principle: Permanent magnet moving coil type

Class: JIS C 1102: 1997 Class 1.0

Operating Position: Horizontal

Scale Length: Approximately 135 mm (Deflection Angle: 90°)

Needle: Bladed Needle (red)

Linemax: 250V (Ammeters only)

Operating Temperature Range: 0 ~ 40°C

Operating Humidity Range: 30 ~ 75% RH

Storage Temperature Range: -10 ~ 50°C

Storage Humidity Range: 25 ~ 80% RH

Dimension: 113 x 106 x 46 mm

Weight: 0.35 kg
