THORLABS S3FC520 带TEC的FP激光源 (520 nm)

Wavelength Minimum: 515 nm

Wavelength Typical: 520 nm

Wavelength Maximum: 530 nm

Full Output Power:

- Minimum: 4.0 mW

- Typical: 8.0 mW

Laser Class: 3B

Fiber: S460HP

Output Fiber Connector: FC/PC, Wide 2.1 mm Key Compatible

Driver

- Power Stability: 15 min: ±0.05 dB, 24 hr: ±0.1 dB (After 1 hr Warm-up at 25 ± 10 °C Ambient)

- Display Accuracy (mW): ±10% of Actual

- Setpoint Resolution: 0.01 mW

- Adjustment Range: ~0 mW to Full Power

TEC

- Stability: 0.005 °C / 1 °C

- Setpoint Accuracy: ±0.25 °C

- Setpoint Resolution: ±0.1 °C

- Adjustment Range: 20 ± 1 °C to 30 ± 1 °C

Environmental:

- Operating Temperature: 15 to 35°C

- Storage Temperature: 0 to 50 °C

Input Power: 115/230 VAC (Switch Selectable), 50 - 60 Hz

Modulation Input: 0 - 5 V = 0 - Full Power, DC or Sine wave Input Only

Modulation Input Impedance: 50 Ω

Modulation Bandwidth

- 5 kHz Full Depth of Modulation

- 30 kHz Small Signal Modulation
