MOSFETs N-CHANNEL 30V 0.5A Torex Semiconductor XP233N05013R-G
Hãng sản xuất: Torex Semiconductor Model: XP233N05013R-G - Liên hệ
Gọi để có giá tốt
TP. Hà Nội: (024) 35.381.269
TP. Đà Nẵng: (023) 63.747.711
TP. Bắc Ninh: (0222)730.39.68
TP. HCM: (028) 38.119.636
Fall Time: 8 ns
Rise Time: 5 ns
Technology: Si
Unit Weight: 6 mg
Channel Mode: Enhancement
Configuration: Single
Mounting Style: SMD/SMT
Transistor Type: 1 N-Channel
Qg - Gate Charge: 780 pC
Number of Channels: 1 Channel
Transistor Polarity: N-Channel
Pd - Power Dissipation: 350 mW
Vgs - Gate-Source Voltage: - 20 V, + 20 V
Typical Turn-On Delay Time: 7 ns
Typical Turn-Off Delay Time: 30 ns
Id - Continuous Drain Current: 500 mA
Maximum Operating Temperature: + 150 C
Minimum Operating Temperature: - 55 C
Rds On - Drain-Source Resistance: 1.5 Ohms
Vds - Drain-Source Breakdown Voltage: 30 V
Vgs th - Gate-Source Threshold Voltage: 900 mV
