ZEISS EVO 10 Electron Microscopy
Manufacturer: ZEISS Model: EVO 10 Origin: Germany - Contact
Call for the best price
Hanoi city: (024) 35.381.269
Danang city: (023) 63.747.711
Bac Ninh city: (0222)730.39.68
HCM city: (028) 38.119.636
Resolution: VP Mode 3 nm, 3.4 nm @ 30 kV SE VP mode with LaB6, W
Acceleration Voltage: 0.2 to 30 kV
Probe Current: 0.5 pA to 5 μA
Magnification: < 7 – 1,000,000×
Field of View: 6 mm at Analytical Working Distance (AWD)
Chamber Dimensions: 310 mm (Ø) × 220 mm (h)
5-Axes Motorized Specimen Stage:
X = 80 mm, Y = 100 mm,
Z = 35 mm, T = -10° to 90º,
R = 360º (continuous)
Maximum Specimen Height: 100 mm
