Rational VMS-6090H Long Stroke CNC Video Measuring System (Air floation) (X,Y: 600×900mm)

Features：

1. Long stroke contributes to wide measuring range.

2. The seft-developed Measuring software has meet various requirements of customers.

3. With features like auto focusing, auto edge finding, powerful programming, and auto measuring, etc.

4. Adopts subpixel subdivision technique to improve resolving power of boundary.

5. Equipped with joystick, which is also able to be programmed by software.

6. SPC data processing system and large quantities of jig measurement.

7. X, Y, Z-axis all adopt servo control system - Quick positioning with high precision, and stable operation.

8. Adopts self-developed sophisticated embedded module control system installed within the instrument, which ensures a more stable operation.

9. Programmed constant current drive for surface cold light source in the 5 rings and 8 zones, which is suitable for complicated workpiece.

10. Guide rails of X and Y-axis are made of granite that possesses of the high stability and rigidity.

11. Perfect straightness granite, ideal flatness grass, and frictionless and wearproof granite guide rail.

12. Detects the measured workpiece’s specific location by laser indicator, which is convenient to position and operate.
