HK Instruments DPG300/PS300 Differential pressure gauge and pressure switch combination (DPG: 0–300 Pa; PS: 30–300 Pa)
Manufacturer: HK Instruments Model: DPG300/PS300 P/N: 109.005.001 - Contact
Call for the best price
Hanoi city: (024) 35.381.269
Danang city: (023) 63.747.711
Bac Ninh city: (0222)730.39.68
HCM city: (028) 38.119.636
Measurement range DPG (Pa): 0–300 Pa
Measurement range PS (Pa): 30–300 Pa
Accuracy of gauge (FS 20 °C): ±2 %
Switching difference: 20 Pa
Accuracy of switching point (Low limit typ.): 30 Pa ±5 Pa
Accuracy of switching point (High limit typ.): 300 Pa ±40 Pa
Electrical rating, resistive load: 3 A / 250 VAC
Electrical rating, inductive load: 2 A / 250 VAC
Maximum pressure: 50 kPa
Service life: > 1 000 000 switching operations
Measuring units: Pa
Environment: Operating temperature: -5...+60 °C; 'Storage temperature: -40...+85 °C
Protection standard: IP54
