Internal Dimensions WxHxD (mm): 50x75x60
External Dimensions WxHxD (mm): 100x161x117
Temperature Range: -20℃ ~ 100℃ (150℃)
Humidity Range: 20%~98%R.H.(10%-98%R.H/5%~98%R.H is a special optional condition)
Analytic Accuracy/Evenness degree of Temperature and Humidity: ±0.01℃; ±0.1%R.H./1.0℃; ±3.0%R.H.
Control Accuracy/Temperature stability of Temperature and Humidity: ±1.0℃; ±2.0%R.H./±0.5°C; ±2.0%R.H.
Heating/Cooling Rate: Approximately 2~15℃/minute (The machine should be with the cooling rate is 515/min and capacity is above 408L)
Inner and Outer Materials: The external box is the SUS304# stainless steel surface strips, the inner box is SUS304# stainless steel.
Insulation Material: High temperature resistant high density polyurethane rigid foam insulation materials.
Cooling System: Air, water cooling/double segment compressor
Protection Devices: Fuse-free switch, overloading protection switch for compressor, high and low voltage coolant protection switch, over-humidity and over-temperature protection switch, fuses, failure warning system
Parts: Recorder (optional), watching window, 50mm testing hole, PL internal bulbs, partition plate, dry and wet ball gauze
Controller: South Korea"TEMI"
Compressor: France's "Tecumseh" Brand/BITZER GERMAN
Power: 3Փ 380VAC±10% 50/60Hz
