UNI-T UT3224 多通道温度测试仪 (24-CH; -200℃~1800℃; 0.1℃)

Display mode: Visual numerical reading, bar chart and curvilinear graph

Index No.: Thermocouple: J,K,T,E,S,N,B,R

Measuring range: -200℃~1800℃ (varies with different thermocouple)

Resolution: 0.1℃

Number of channel: 24

Scanning speed: Fast, slow

Sorting function: Build-in data sorting, can set upper/lower temperature limit alarm for each channel

Alarm function: Upper/lower temperature limit alarm

User calibration: User calibration of each channel is allowed

Button functions: Lock -keyboard lock, Print Sc -screenshot

System setup Language: Chinese/English, key tone setting

Storage: FAT storage function (supports USB disk storage, mobile hard disk drive is not supported)

Interface & protocol: RS-232 and USB communication interface, SCPI protocol

Upper computer software: Yes

Display mode: Test temperature range / Accuracy

- T-type Thermocouple: -150℃-0℃, 0℃~400℃ / ±1℃, ±0.8℃

- K-type Thermocouple: -100℃-0℃, 0℃~1350℃ / ±1.2℃, ±0.8℃

- J-type Thermocouple: -100℃-0℃, 0℃~1200℃ / ±1℃, ±0.7℃

- N-type Thermocouple: -100℃-0℃, 0℃~1300℃ / ±1.5℃, ±0.9℃

- E-type Thermocouple: -100℃-0℃, 0℃~850℃ / ±0.9℃, ±0.9℃

- S-type Thermocouple: -100℃-0℃, 100℃~300℃, 300℃~1750℃ / ±4.5℃, ±3℃, ±2.2℃

- R-type Thermocouple: 0℃-100℃, 100℃~300℃, 300℃~1750℃ / ±4.5℃, ±3℃, ±2.2℃

- B-type Thermocouple: 600℃-800℃, 800℃~1000℃, 1000℃~1800℃ / ±5.5℃, ±3.8℃, ±2.5℃

Power: AC 100~240V; 50/60Hz

Display: 4.3-i nch LCD screen

Product net weight: 3.5kg

Product size (WxHxD): 340mm X 214mm X 89mm

Standard accessories:

- Power cord conforming to the standard of the destination country

- USB interface cable x1

- 8G U-disk x1

- Channel identifier x1

- (UT3208/16/24/32 correspond to 1/2/3/4 set of test lead)

- K-type test lead temperature range: -100~200℃

- UT-T21M: K-type thermocouple test lead module

Optional accessories: Thermocouple sensor: T,J,Z,N,S,E,B,R,and many more
