Wavelength Range : 800 - 1800 nm
Bandwidth Range: DC - 510 kHz
NEP(c): 4.63 x 10^-12 to 1.76 x 10^-10 W/Hz^1/2
Active Area(d,e): 19.6 mm^2 (Ø5.0 mm)
Operating Temperature Range: 10 to 40 °C
Power Supply Included: Yes
(c) A noise equivalent power (NEP) range is given for these switchable gain detectors. For specific gain specifications, please see manual.
(d) Click on the links to view an image of the detector element.
(e) The detector active area surface is flush with the front the housing
