ACA: 400A /±(2.0%rdg+3dgt)
ACV: 400 /600V ±(1.2%rdg+3dgt)
Ω: 4kΩ /±(1.5%rdg+3dgt)
Buzzer sounds:< 100Ω
Conductor size: 27mm Max.
Low battery Indication: yes
Dimensions:197(L) × 65(W) × 33(D)mm
Weight:250g
Power source: 9V(6F22) × 1
Details
|
FEATURES |
● Full auto range for V.A and Ω functions. ● Data hold function freezes the reading in dimly lit or hard to reach places. ● Low battery indication. ● Built-in buzzer for continuity test. ● Safety design throughout with no exposed metal parts. Shielded banana plugs and recessed input terminals. ● Ohm function ideal for checking continuity of relays transformers and motor coils.
|
|
SPECIFICATIONS |
|
|
|
AC A |
400A ±(2.0%rdg+3dgt) : 50/60Hz |
AC V |
400 / 600V ±(1.2%rdg+3dgt) : 40-500Hz |
Ω |
4kΩ ±(1.5%rdg+3dgt) |
Buzzer sounds |
< 100Ω |
Conductor size |
27mm Max. |
Low battery Indication |
 |
Dimensions |
197(L) × 65(W) × 33(D)mm |
Weight (battery Included) |
Approx. 250g |
Power source |
9V(6F22) × 1 |
Safety standard |
EN 61010-1 CAT II 600V EN 61010-2-32 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
