NEWARE MHW-25-S-16CH 迷你一体化测试系统 (200L, 0～60°C)

Nominal capacity: 100L x 2

Innernal size: W 500 mm D 500 mm H 400 mm

External size: W 600 mm x D 920 mm x H1920 mm

Net weight: About 260kg

Test the environmental conditions: Ambient temperature is + 25℃, relative humidity is 85%, with no sample in the test box (no load)

Temperature range: 0～60℃

Temperature fluctuation degree: 1℃ (equivalent to ± 0.5℃, with no load and stable temperature)

Temperature deviation: ± 2.0℃ (when no load and temperature is stable)

Heat-up time 25℃ 60℃ 30 min (no-load, average nonlinearity)

Cooling down time: 25℃ 0℃ 50 min (no load, average nonlinear)
