MKS AS11900G03 压力输入模块

Specifications

Type: Pressure Input I/O Module

ADC Native Resolution: 14-bits

AI latency and repeatability: Response Time: 300 µsec ±10%

Number of Inputs: 4, Single Ended (1 for each pressure signal input)

Output Voltage Range: Voltage: 0-10V @ 13 bit

Power Consumption:

24 V Core: 3.5 W

24 V I/O: Max 120 W (When all 4 pressure devices consume 0.8 Amp max each from ±15 V power supply)

Anti-alias HW Filtering: 200 Hz ±20%, 6 dB/octave minimum

Maximum Current Delivery per connector: 0.8 Amps

Input Voltage: 24 VDC

Maximum error over full range: ±0.15% of Full Scale (20 to 30°C)

Minimum Input CMRR: 50dB, 0-1kHz

Minimum Input Impedance: 1 Meg-ohm

MTBF: 10 years at 80% confidence level

Protection: ESD to IEC 61000-4-2 ±4 kV contact, short to 24 V, +15 V, or -15 V

Sampling Rate: 6.25 kHz (160 µsec, for all 4 channels)

Operating Temperature: 0 to 40°C, with 2°C upper limit reduction per 1000 ft above sea level

Storage Temperature: -40 to 75°C

Altitude: up to 2000 meters

Humidity: 5 - 95% non-condensing

Dimensions: 52.5 x 125 x 92.3 mm (W x H x D)

Mounting: DIN rail

For specific range please check the attachment below!
