Medmay MMIC60S 立体放大显微镜 (54~75mm)

View tube:Binocular, 45° Tilt, IPD adjustment: 54~75mm

Eyepiece (Optional):10×(Φ20mm) / 15×(Φ16mm) / 20×(Φ12.5mm)

Objective (Optional):(1X, 2X) or (1X, 3X) or (2X, 4X)

Auxiliary objective (Optional):AL0.5X, AL2X

Magnification:a: Eyepiece 10×(Φ22mm)

                      b: Eyepiece 15×(Φ16mm)

                      Objective 1X, 2X, magnification: 10X, 20X Objective 1X, 2X, magnification: 15X, 30X

                      Objective 1X, 3X; magnification: 10X, 30X Objective 1X, 3X; magnification: 15X, 45X

                      Objective 2X, 4X; magnification: 20X, 40X Objective 2X, 4X; magnification: 30X, 60X

                      c: Eyepiece 20×(Φ12.5mm)

                      Objective 1X, 2X, magnification: 20X, 40X Objective 2X, 4X; magnification: 40X, 80X

                      Objective 1X, 3X; magnification: 20X, 60X

Light source:Upper LED, the brightness is adjustable. AC110V~240V.

Black and white board:Φ95mm

Standard configuration:Eyepiece: 10X, Objective: 2X, 4X, Upper LED ring light
