KEYSIGHT 87104C 多端口同轴开关 (DC to 26.5 GHz, SP4T Terminated)

Frequency range: DC to 26.5 GHz

Specifications

Life: 5,000,000 cycles minimum

Switching speed: 15 ms maximum

Indicator specifications

Maximum withstand voltage: 60 V

Maximum current capacity: 150 mA

Maximum “ON” resistance: 2.5 Ω

Maximum “OFF” resistance: 10 G Ω

Maximum power rating

Into internal termination: 1 W CW50 W peak, 10 µs max pulse width, not to exceed 1 W average

Into thru path Hot switching: 2 W CW100 W peak, 10 µs max pulse width, not to exceed 2 W average

Environmental specifications

Operating temperature: –25 to 75 °C

Storage temperature: –55 to 85 °C

RFI: Per MIL-STD-461C, RE02, Part 4

Magnetic field: <

Detail

Datasheet


Features

• SP4T and SP6T configuration

• Magnetic latching

• Operating life of 10 million cycles, typical

• Repeatability of 0.03 dB up to 5 million cycles ensures

• accurate system measurements and reduces calibration intervals

• Excellent isolation, typically >90 dB at 26.5 GHz

• Opto-electronic indicators and interrupts

• Terminated ports

• TTL/5 V CMOS compatible (optional)
