Measuring range

            5V: 2.5x104 to 1x1011Ω

            10V: 5x104 to 2x1011Ω

            15V: 7.5x104 to 3x1011Ω

            25V: 1.25x105 to 5x1011Ω

            50V: 2.5x105 to 1x1012Ω

            100V: 5x105 to 2x1012Ω

Accuracy of measuring voltage: ± 3% of setting voltage value

Output current:  Max. 50mA

Measuring accuracy    ± 10% (within 10 times range of min. value on each range at 20°C

Display: LCD (digital & analog display)

Standard function: timer, comparator (alarm), remote start, HV-EN, RS-232C

Ambient temperature: 5 to 40°C

Ambient humidity: less than 85%RH

Power consumption: Selectable 100, 120, 220 or 240V AC ±10%, 50/60Hz, 25VA max.

Dimensions, mass: 284mm(11.18in)W x 139mm(5.47in)H x 215mm(8.46in)D, 4.3kg(151.7oz)

Standard accessories: measuring rods (red & black) x 1 pair, power cord x 1pc., instruction manual x 1
