EXTECH EX505 型11功能重型真有效值工业万用表

Display Counts: 4,000 count

True RMS

Basic Accuracy: 0.5%

DC/AC Voltage: 0.1mV to 1000VDC, 0.1mV to 1000VAC

DC/AC Current: 0.1μA to 10A

Resistance: 0.1Ωto 40MΩ

Capacitance: 0.01nF to 100μF

Frequency (electrical): 5Hz to 1kHz

Frequency (electronic): 0.001Hz to 10 MHz

Temperature: -20 to 750°C

Duty Cycle: 0.1 to 99.90%

Diode/Continuity: yes

Dimensions:  184x83x57mm

Weight: 12.3oz (349g)

Complete with double molded test leads, magnetic hanging strap, Type K bead wire

temperature probe, carrying case, and one 9V battery


  • 1000V input protection on all functions
  • Dual sensitivity frequency functions
  • Large backlit LCD
  • Diode open circuit voltage of 2.8V DC
  • Auto power off with disable feature
  • 4,000 count
  • 0.5% accuracy
  • Data Hold and Relative
  • 10A max current


  • Double molded test leads
  • Magnetic hanging strap
  • Type K bead wire temperature probe (-22 to 572°F/-30 to 300°C)
  • Carrying case
  • One 9V battery
