CEM FC-33 3 in 1 Mini AC, AC/DC Clamp Meters (AC/DC-80A)

Function: Max Range -  Basic Accuracy - Max. Resolution

AC Current

2A  ;  ±(3.0%+8d)  ;  1mA

80A  ;  ±(3.0%+8d)  ;  100mA

DC Current

2A  ;  ±(2.8%+8d)  ;  1mA

80A  ;  ±(2.8%+8d)  ;  100mA

Diode: Open circuit voltage 1.5V, Test current 0.3mA (FC-35 only)

Continuity: Buzzer sounds at 100Ω (FC-35/36 only)

Non-contact Voltage detection : 100~600VAC

Size (H x W x D): 178mm x 65mm x 32mm

Weight: 170g


Accessories: Test leads, clamshell with carrying case and two “AAA”1.5V batteries.


Detail

Datasheet


Features

FC-31

FC-32

FC-33

FC-35

FC-36

True RMS

*

AC/DC Voltage, Resistance, Continuity, Diode check

*

*

Digital display counts

2000

2400

2400

2000

2000-9999

0.7˝ Jaw opening

*

*

*

*

*

Non-contact Voltage detector and Flashlight

*

*

*

*

*

AC Current

*

*

*

*

DC Current

*

*

*

Data Hold function

*

*

*

*

MAX/MIN Hold function

MAX

MAX

*

DCA Zero function

*

*

*

Peak Hold function

*

Auto Power Off

*

*

*

*

*

Low battery indication

*

*

*

*

*

Backlight Display

*

*

*

*


Specifications

Function

Max Range

Basic Accuracy

Max. Resolution

FC-31

FC-32

FC-33

FC-35

FC-36

AC Current

2A

±(3.0%+8d)

1mA

*

20A

±(3.0%+8d)

10mA

*

80A

±(3.0%+8d)

100mA

*

200A

±(3.0%+8d)

100mA

*

*

*

*

DC Current

2A

±(2.8%+8d)

1mA

*

80A

±(2.8%+8d)

100mA

*

200A

±(3.0%+8d)

100mA

*

*

Frequency

40~51Hz

±(1.2%+5d)

0.01Hz

*

51~510Hz

±(1.2%+3d)

0.1Hz

*

0.51~1kHz

±(1.2%+3d)

0.001kHz

*

Voltage DC

600V

±(0.5%+1d)

0.2-600V auto

600.0V

Voltage AC

600V

±(1.5%+2d)

0.2-600V auto

600.0V

Resistance

20M

±(3.0%+5d)

0.2k-20MΩ auto

999.9Ω

Diode

Open circuit voltage 1.5V, Test current 0.3mA (FC-35 only)

Continuity

Buzzer sounds at 100Ω (FC-35/36 only)
