CEM DT-391 AC/DC Clamp Meters (AC-200A, AC/DC-1000V)

Function: Max Range - Basic Accuracy

Voltage DC: 1000V  ;  ±(0.8%+3d)

Voltage AC: 1000V  ;  ±(1.0%+3d)

Current AC: 200A  ;  ±(3.5%+5d)

Resistance: 60MΩ  ;  ±(3.0%+5d)

Capacitance: 6000mF  ;  ±(2.5%+5d)

Non contact voltage test: 600V  ;  ±(2.5%+5d)

Continuity check: Buzzer sounds at 50Ω

Diode test: Test current 0.35mA 3V

Detail

Datasheet


Features

390

391

200A AC Current measurement

*

*

Digital display counts

6000

6000

Display type(Negativity display)

*

*

Compact size

*

*

Data Hold & MAX/MIN Function

*

*

Peak Value & Inrush Current

*

Backlight for button, knob Switch & Flashlight

*

*

Low battery indication

*

*

17mm Jaw opening

*

*

Auto sense Voltage

*

*

NCV

*

*

Low Z & True RMS

*

*

Non contact voltage test

*


Specifications

Function

Max Range

Basic Accuracy

390

391

±(0.8%+3d)

1000V

±(0.8%+3d)

*

*

Voltage AC

1000V

±(1.0%+3d)

*

*

Current AC

200A

±(3.5%+5d)

*

*

Resistance

60MΩ

±(3.0%+5d)

*

*

Capacitance

6000mF

±(2.5%+5d)

*

*

Non contact voltage test

600V

±(2.5%+5d)

*

LoZ (600V)

~3KΩ

Continuity check

Buzzer sounds at 50Ω

Diode test Test

current 0.35mA 3V
