CEM DT-338 Mini AC/DC Clamp Meters (AC/DC-80A/600V, True RMS)

Function: Max Range - Max. Resolution - Basic Accuracy

Current AC: 80A  ;  1mA  ;  ±(2.5%+5d)

Current DC: 80A  ;  1mA  ;  ±(2.5%+4d)

Voltage AC: 400mV~600V  ;  0.1mV  ;  ±(2.0%+4d)

Voltage DC: 400mV~600V  ;  0.1mV  ;  ±(1.5%+3d)

Resistance: 400Ω~40MΩ  ;  0.1Ω  ;  ±(1.5%+2d)

Frequency: 5Hz~10MHz  ;  0.001Hz  ;  ±(1.2%+3d)

Capacitance: 40mF  ;  0.001nF  ;  ±(3.5%+10d)

Temperature

-20ºC~+760ºC  ;  0.1ºC  ;  ±(2.0%+3ºC)

-4ºF~+1400ºF  ;  0.1ºF  ;  ±(2.0%+ 3ºF)

Diode Check: Test current of 0.3mA, Open circuit voltage 3.0V (338)

Continuity Check: Threshold 50Ω

Size(HxWxD): 210mm x 70mmx 37mm

Weight: 200g


Accessories: Test leads, Gift box with carrying case, 9V battery.

Detail

Datasheet


Features

DT-337

DT-338

DT-339

Small jaw size

0.5˝

0.8˝

0.7˝

1mA high resolution

*

*

*

True RMS AC clamp-on multimeter

*

*

Type K Temperature function

*

*

Digital clamp tester for AC/DC current measurement

*

*

*

Providing wide measuring range from very small to large current

*

*

*

Designed to safety standard IEC 61010-2-032: CAT III 600V and pollution degree 2

*

*

*

Display counts

4000

4000

5000

Auto power off & Data hold function

*

*

*

Peak hold ,Max/Min hold and Relative functions

*

Max/Min

Advanced functions include Capacitance, Frequency

*

*

Flashlight

*


Specifications

Function

Max Range

Max. Resolution

Basic Accuracy

DT-337

DT-338

DT-339

Current AC

80A

1mA

±(2.5%+5d)

*

*

*

Current DC

80A

1mA

±(2.5%+4d)

*

*

*

Voltage AC

400mV~600V

0.1mV

±(2.0%+4d)

*

*

*

Voltage DC

400mV~600V

0.1mV

±(1.5%+3d)

*

*

*

Resistance

400Ω~40MΩ

0.1Ω

±(1.5%+2d)

*

*

*

Frequency

5Hz~10MHz

0.001Hz

±(1.2%+3d)

*

*

*

% Duty

5%~99.9%

0.10%

±(1.2%+3d)

*

Capacitance

40mF

0.001nF

±(3.5%+10d)

100uF

*

500.0uF

Temperature

-20ºC~+760ºC

0.1ºC

±(2.0%+3ºC)
±(2.0%+ 3ºF)

*

*

-4ºF~+1400ºF

0.1ºF

Diode Check

Test current of 0.3mA, Open circuit voltage 3.0V (338)

*

*

*

Continuity Check

Threshold 50Ω

*

*

*
