SIGLENT SDS2302X オシロスコープ (300MHz; 2CH+EXT; 2GSa/s)

Bandwidth: 300MHz

Sampling rate (Max.): 2GSa/s

Channels: 2+EXT

Memory depth (Max.): 140Mpts (Single-Channel), 70Mpts (Dual-Channel)

Waveform capture rate (Max.): 140.000wfm/s (normal mode), 500.000wfm/s (sequence mode)

Trigger type: Edge, Slope, Pulse width, Window, Runt, Interval, Dropout, Pattern, Video

Serial Trigger: IIC, SPI, UART/RS232, CAN, LIN

Decoder type (Optional): IIC, SPI, UART/RS232, CAN, LIN

16 digital channels (MSO Option): Maximum waveform capture rate up to 500 MSa/s, Record length up to 14 Mpts/CH

Waveform generator (Optional): Single channel, Max. frequency up to 25MHz, 125MSa/s sampling rate, 16Kpts wave length

I/O: USB Host, USB Device, LAN, Pass/Fail, Trigger Out

Probe (Std): SP2030A 300MHz; 1 pcs for each channel

Display: 8 inch TFT LCD (800x480)
