Bus Connector: USB 2.0
Oscilloscope Maximum Bandwidth: 50 MHz
Maximum Sample Rate: 50 MS/s
Number of Voltage Input Channels: 2
Analog Input Resolution: 8 bits
Oscilloscope Onboard Memory Size: 4 MB/ch
Analog Input Voltage Range: -20 V to 20 V
Onboard Digital Downconverter: No
Acquires and analyzes time‐ and frequency-domain analog waveforms.
Oscilloscope Devices are flexible, software‐defined instruments that are versatile enough for both time‐ and frequency‐domain measurements and are offered in industry-standard form factors like PCI and USB. They feature up to eight channels that can sample at speeds up to 2 GS/s. The devices also feature numerous triggering modes, deep onboard memory, and driver software API that includes data streaming and analysis functions.
