Hoyamo SHL-160 ポータブルリーブ硬さ試験機 (170 to 960)

Hardness system: Leeb (HL), Brinell (HB), Rockwell A (HRA), Rockwell B (HRB), Rockwell C (HRC), Vickers (HV) and Shore (HS)

Measurement range: HLD (170 to 960), HRA (59 to 85), HRB (13 to 100), HRC (18 to 68), HB (19 to 655), HV (80 to 976), HS (32 to 100)

Measuring direction: 360° (vertical downward, obliquely downward, horizontal, oblique upward, vertical upward)

Measuring materials: Steel and cast steel, alloy tool steel, stainless steel, gray cast iron, ductile iron, cast aluminum alloy, copper-zinc alloy (brass), copper-tin alloy (bronze), pure copper and forged steel

Display: LCD, 128×64 graphics dot matrix LCD

Print function: Thermal print head, quiet, ready to print measurement results

Printing paper: width 57.5±0.5mm, diameter 30mm

Data storage: 373~2688 groups (impact times 32~1)

Communication interface: standard USB2.0

Charging power supply: 9VDC, 220VAC

Charging time: 4 to 5 hours

Battery: 7.4V, lithium battery (1500mAh)

Ambient temperature: 0~40°C

Storage temperature: -25~70°C

Working hours: about 300 hours

Standard configuration:

  • Main part

  • D type impact device

  • Small support ring

  • Nylon Brush (I)

  • High value Leeb hardness block

  • Charger

  • Communication cable

Optional accessories:

  • Data processing software (application on computer)

  • Various shaped impact devices and support rings

  • High, medium and low value hardness block
